Kärcher MC 130 - Electrical Connections; Water Connections

66 English
Rear connections
Right-hand side connections
(1)AUX hydraulic connection, raise/lower
(2)Hydraulic PTO (40 l/min)
Left-hand side connections
(1)AUX hydraulic connection, raise/lower
(2)Return line (40 l/min)
Electrical connections
Terminology electric PTO
Power Take Off = electric power output
Electrical connections for front attachment
1 Attachment detection
Electrical connections for rear attachment
1 Attachment detection
2 21-pin connection for rear attachment
Water connections
Spray water connections
Right-hand side connections
1 Right side brush dust spray water
Left-hand side connections
1 Left side brush dust spray water
2 Suction mouth spray water
