Kawai MP8 - MIDI Jacks; Usb Jack; Power Switch; Power Receptacle

11
5. MIDI JACKS
These jacks are used to connect the MP8 with external MIDI devices such as a MIDI
sound module or a MIDI sequencer.
6. USB JACK
This jack is used to connect the MP8 with a personal computer. See page 55 for
details.
7. POWER SWITCH
Turns the MP8 ON or OFF.
8. POWER RECEPTACLE
Connect the power cable, which is included in the MP8 package, to this receptacle.
Keyboard amplifier
PA equipments
(Ex. Mixer, Multi-track recorder)
Expression
(Optional)
Terminal B
Terminal A
MIDI devices
(Ex. External Sound module, External Sequencer,
Keyboards, Personal Computers)
Footswitch
(Optional)
