2.3 System Realtime Message
Status
F8H Clock
FAH Start
FCH Stop
*Sending [SW] External Seq. Start/Stop
3. Exclusive Data
3.1 Universal Realtime Exclusive Message
Master Volume
Format :F0 7F 7F 04 01 ll mm F7
mm=MSB of Master Volume
ll=LSB of Master Volume
3.2 MP8 Dump Message
MP8 can receive these dump data, and also can transmit by the panel operation with System switch.
Also,MP8 can receive MP4/9500/9000’s dump data.(Please see the manual of MP4/9500/9000 about the format.)
*note: Part of MP9000/95000’s tone or parameters is replaced to the MP8’s one.
a: MP8 Dump CURRENT
Format :F0 40 <ch> 20 00 0E <DATA> F7
<ch> :MIDI ch (00~0F)
<DATA> :432bytes *Current Setup data in edit buffer or to edit buffer
b: MP8 Dump ALL(Setup 1-64)
Format :F0 40 <ch> 21 00 0E <DATA> F7
<ch> :MIDI ch (00~0F)
<DATA> :110,592bytes *All Setup 1~256 (Setup1-1-A ... Setup 8-8-D)
3.3 Setup Data Format
The structure of the one Setup patch [432bytes]
(common DATA) + (Zone 1,2,3,4 Int DATA) + (Zone 1,2,3,4 Ext DATA)
3.3.1 Common DATA
No. PARAMETER VALUE
1-2 -reserved-
3-16 Name 1st~14th ASCII
17 Zone Select 0-3 (0-3:Zone1-4)
18-21 Zone1-4 Edit Section 1,2 0(1:INT, 2:EXT)
22-25 Zone1-4 Mode 0,1,2(0:BOTH, 1:INT, 2:EXT)
26-29 Zone1-4 On/Off 0,1 (0:off, 1:on)
30 Knob Mode 0-3 (0:Effect, 1:EQ, 2:tone, 3:CC#)
31 EQ Lo 52~64~76 (-12~0~+12[dB])
32 EQ Mid Lo 52~64~76 (-12~0~+12[dB])
33 EQ Mid Hi 52~64~76 (-12~0~+12[dB])
34 EQ Hi 52~64~76 (-12~0~+12[dB])
35 -reserved-
36 -reserved-
37 Reverb Type 0~6 (see p.22)
38 Reverb Time 0-127
39-42 Zone1 MIDI CC# A-D 0-119
43-46 Zone2 MIDI CC# A-D 0-119
47-50 Zone3 MIDI CC# A-D 0-119
51-54 Zone4 MIDI CC# A-D 0-119
