Operating Instructions KBL 3500
10
7
3
2
2
5
1
4
6
1 Body fan 5 Lower air-discharge opening
2 Upper air intakes 6 Power/timer connection
3 Canopy power cable 7 Upper air-discharge opening
4 Display control cable
Back sideBack side
