Operating Instructions KBL 3500
The cleaning and care instructions have to be observed.
Replacing the bed pane requires two people.
Fold up the canopy of the sunbed.
Undo the 2 fl at-head srews on the left-hand and on the right-hand side of
the bed pane.
One person takes hold of the right-hand side, one of the left-hand side of
the bed pane; fold it up until you almost reach the canopy and pull it out
towards the front.
Assembly is performed in reverse order. Ensure the correct placement of
the pane profi le in the hinge profi le when inserting the new pane.
1.
2.
3.
4.
Replacing the
bed pane
Replacing the
bed pane
