Operating Instructions KBL 3500
40
Remove the tubes by turning each tube a quarter forwards or backwards
and pulling it out.
When cleaning the tubes, use warm water and a chamois. Do
not use any aggressive or alcoholic cleansing agents.
When replacing the tubes, replace the starters fi rst.
Installing the tubes: Make sure that the inscription on the
tubes is visible, or else there will be no tanning effect.
Assembly is performed in reverse order. The quick-release
fasteners of the pane are screwed down as follows: Bring
the screw slot into a horizontal position with a screwdriver
and press against it until the lock catches.
Reset the counter for the power-on hours of the tubes in
the service menu (Roehr.Std/poh tubes).
6.
7.
8.
9.
10.
11.
