KBR multicomp F144-MS-1V1C1TI6DO6RO-3 User Manual

Rev. 1.00
22586_EDEBDA0253-0318-1_EN
12
KBR multicomp F144-3 6DO/6RO Control and display panel
Default controller settings after reset:
 Consumption target cos phi: 0.95 inductive
 Recovery target cos phi: 1.00 (cannot be changed)
 Alarm cos phi: 0.92 inductive
 Main transformer current: Primary current 1000 A
Secondary current 5 A
 Measuring voltage: Primary voltage 400 V Ph-Ph
(corresponds to 230V Ph-N )
Secondary voltage 400 V Ph-Ph
(corresponds to 230V Ph-N )
 Rot. eld U: L1-N
 Rot. eld I: L1
 Current attenuation coecient: 0
 Voltage attenuation coecient: 0
 Attenuation coecient Qmiss: 0
 Alarm delay: 20 minutes (1200 s)
 Thyristor idle time: 30 ms
 Contactor idle time: 30 seconds
 Thyristor switching interval: 50 ms
 Contactor switching interval: 8 seconds
 Hysteresis connection: 100% of lowest stage power
 Hysteresis switch-o: 100% of lowest stage power
 Contactor stage operating cycle limit: 80000
 Operating cycle count: active
 Stage switching mode: Automatic
 Sampling rate: Automatic
 Harmonics monitoring: Activated by set limit
 Limit THD: 8%
 Stage power: Not set
 Max. stage power per switching cycle: 0 kvar
 Thyristor discharge time: 20 ms
 Contactor discharge time:180 seconds
 Password: No password (9999, meaning all functions
are accessible)
 Language display: English
 Contrast setting: 5
 Brightness setting: 5
 Dimmer brightness: 0
 Light load limit: 15 mA
 Light load delay: 60 minutes
