KBR multicomp F144-MS-1V1C1TI6DO6RO-3 User Manual

Rev. 1.00
22586_EDEBDA0253-0318-1_EN
13
KBR multicomp F144-3 6DO/6ROControl and display panel
 Temperature measurement: On
 Output 12 as stage or fan: Fan output
 Fan switch-on temperature: > 28 °C
 Fan switch-o temperature: < 23 °C
 System switch-o temperature: > 48°C
 System switch-on temperature: < 43°C
 Learning mode menu display: O
 Touch tones: On
Error message dialog after reset:
No measuring voltage: Message and alarm relay
No stage power: Message and alarm relay
PFC too small: Message and alarm relay
THD too high: Message and alarm relay
Operating cycle limit exceeded: Message and alarm relay
No measuring current: Message and alarm relay
light load operation: Message and alarm relay
Temperature switch-o : Message and alarm relay
The controls in the compensation systems are preset.
The following parameters need to be checked or set:
 Target cos phi in accordance with the electricity supplier regulations (for kVA
tari cos phi = 1)
 Primary current and secondary current in accordance with input current
transformer.
 Voltage transformer ratio, if required
NOTE
Upon delivery, the bus protocol is set to: Modbus RTU, baud rate 38400, parity
even
This setting can only be changed manually on the device.
Performing a "Reset to default settings" has no e ect on changed settings.
