KBR multicomp F144-3 6DO/6RODescription of the display window
NOTE
The stage outputs 1 to 6 are optocoupler outputs and the stage outputs 7 to 12
are relay outputs.
 Switching threshold fan on:
In this submenu, you can change the switch-on threshold for the fan output.
It can be varied between 0°C and 60 °C.
 Switching threshold fan o :
In this submenu, you can change the switch-o threshold for the fan output.
It can be varied between 0°C and 60 °C.
NOTE
The fan has a run-on time of 30 minutes to prevent unnecessarily frequent
switching.
 Switching threshold system o :
In this submenu, the switching threshold for switching o the system can be
varied. It can be varied between 0°C and 60 °C.
 Switching threshold system on:
In this submenu, the switching threshold for switching on the system can be
varied. It can be varied between 0°C and 60 °C.
 Bus mode:
In this submenu, the bus protocol of the device can be set.
to KBR eBus or Modbus RTU.
The KBR eBus setting is used for testing purposes.
If Modbus RTU is selected, you can set the transmission parameters here. The
supported transmission parameters are:
Baud rate (baud) 4800, 9600, 19200, 38400
Parity even, odd, none
Databits 8
Stopbits 1 for even and odd, 2 for Parity none
 Learning mode:
In this submenu, you can show or hide the submenu item "Learning mode
activate" (in the Commissioning menu).
 Touch tones:
In this submenu, you can turn the key sounds (which sound if a sensor button
is pushed) on or o .
 EEP delete:
For production purposes only.
