KEB COMBIVERT F5-G / B
Name: Basis
04.12.01
3
Section PageDate
© KEB Antriebstechnik, 2001
All Rights reserved
Chapter
HardwareControl Cards
3.1.1 Survey
3.1 Control Units
In this application manual the control cards F5-BASIC and F5-GENERAL are described.
The control card F5-GENERAL is available in two version, one version for housing
size B and another version for larger housings. The control cards F5-BASIC and F5-
GENERAK in the B-housing have a restriced functional range compared to the large
F5-GENERAl control card. These restrictions generally refer to the missing hardware
components and the appropriate parameters.
3. Hardware
The following section is to get an overview of the F5 control cards.
Contol card BASIC GENERAL B GENERAL >=D
Inputs
Set value input 1 2 2 (optionally +1)
Digital inputs (programmable) 5 8 8
Înternal inputs 4 4 4
External supply of the control card - X X
Encoder interface - - X (optionally)
Scan time of the in- and outputs 2 ms 1 ms 1 ms
Outputs
Analog outputs ±10 V 1 1 2
Digital outputs - 2 2
Relay outputs 2 2 2
Internal outputs 4 4 4
Potential-free operator output X X X
Functions
Parameter sets 8 8 8
Aux function X X X
Brake control X X X
DC braking X X X
Energy saving function X X X
Speed search X X X
Autoboost X X X
Slip compensation X X X
Fixed frequencies X X X
Electronic motor protection X X X
Power on counter X X X
Power off function X X X
PID controller X X X
Jerk lever starting by s-curves X X X
Bus response time 2 ms 1 ms 1 ms
Suitable for
Housing size A X - -
Housing size B X X -
Housing size D X - X
Housing size E X - X
Housing size >= G X - X
