3 1
KEB COMBIVERT F5-G / B
4
Name: Basis
04.12.01
Chapter Section Page Date
© KEB Antriebsteclnik, 2001
All Rights reserved
Hardware Control Cards
3.1.2 Terminal strip X2A
123456789
10 11 12 13 14 15 16 17 18 19 20 21
22 23 24 25 26 27 28 29
157810111415162022 24 25 26 27 28 29
GENERAL
BASIC
PIN Function Name Description
1 + Set Value input 1 AN1+ The input signal (0...±10 V; 0...±20 mA and 4...20 mA) is determined
2 - Set Value input 1 AN1- with An.0/10. Specification and control see chap. 6.2.2.
3 + Set Value input 2 AN2+ Resolution: 12 Bit (BASIC and GENERAL B-housing: 11 Bit)
4 - Set Value input 2 AN2- Scan time: 1 ms (BASIC: 2 ms)
at directly setpoint input: 250 µs (see chapter 6.4.2)
5 Analog Output 1 ANOUT1 The variable for outputting at analog output 2 is determined with
An.31 / 36. Specification and control see chap. 6.2.11.
6 Analog Output 2 ANOUT2 Voltage range: 0...±10V, Ri = 100 Ω, Resolution: ±10 Bit
7 +10 V Output CRF Reference voltage output +10 VDC +5% / max. 4 mA for set value
potentiometer.
8 Analog Mass COM Mass for analog in- and outputs
9 Analog Mass COM Mass for analog in- and outputs
10 Progr. Input 1 I1 Specifications, control and programming of the digital
11 Progr. Input 2 I2 inputs see chap. 6.3.1...6.3.11
12 Progr. Input 3 I3 All digital inputs are free programmable.
13 Progr. Input 4 I4 The control release is firmly linked with the input ST, but can be
14 Progr. Input Forward F additional occupied with other functions.
15 Progr. Input Reverse R Ri = 2,1 k
16 Progr. Input Control Rel. ST Scan time: 1 ms (BASIC: 2 ms)
17 Progr. Input Reset RST
18 Transistor Output 1 O1 Specifications, control and programming of the digital
19 Transistor Output 2 O2 transistor outputs see chap. 6.3.12...6.3.22,
a total of max. 50 mADC for both outputs
20 +24 V Output U
out
approx. 24V DC output (max.100 mA)
21 20...30 V Input U
in
Ext. supply voltage for digital in-/outputs, potential 0V (X2A.22/23)
22 Digital Mass 0V Potential for digital in-/outputs
23 Digital Mass 0V Potential for digital in-/outputs
24 Relay 1 /NO contact RLA Programmable relay output 1 (Terminal X2A.24...26);
25 Relay 1 /NC contact RLB Programmable relay output 2 ( Terminal X2A.27...29)
26 Relay 1 /switching contact RLC Specifications, control and programming of the relay outputs
27 Relay 2 /NO contact FLA see chapter 6.3.11...6.3.17
28 Relay 2 /NC contact FLB max. 30 V DC, 1 A
29 Relay 2 /switching contact FLC
