6 3
KEB COMBIVERT F5
8
Name: Basis
16.04.02
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All rights reserved
Functional Description Digital In- and Outputs
6.3.11 Assignment of
the Inputs
List of parameters, that can be assigned with inputs:
Parameter Name Preadjustment
oP.19 Fixed value / input selection 1 16 (I1)
oP.20 Fixed value / input selection 2 32 (I2)
oP.56 Motorpoti increase / input selection 0
oP.57 Motorpoti decrease / input selection 0
oP.58 Motorpoti Reset / input selection 0
oP.60
1)
Rotation forward (Run) / input selection 4 (F)
oP.61
1)
Rotation reverse (Stop) / input selection 8 (R)
di. 9 Reset / input selection 3 (ST+RST)
di.10
2)
Edge evaluation for Reset / input selection 3 (ST+RST)
Pn. 4 External fault / input selection 64 (I3)
Pn.23 Ramp stop / input selection 0
Pn.29 DC-braking / input selection 128 (I4) 0 at F5-M
uF. 8 Energy-saving function / input selection 0
Fr. 7 Parameter set / input selection 0
Fr.11 Reset set / input selection 0
An. 3 AN1 save trigger / input selection 0
An.13 AN2 save trigger / input selection 0
An.23 AN3 save trigger / input selection 0
LE.17 Timer 1 Start / input selection 0
LE.19 Timer 1 Reset / input selection 0
LE.22 Timer 2 Start / input selection 0
LE.24 Timer 2 Reset / input selection 0
cn.11 PID reset / input selection 0
cn.12 I reset / input selection 0
cn.13 Fade in reset / input selection 0
1)
By selecting the source of rotation (oP.1) the adjustment can be changed from
forward/reverse to Run/Stop.
2)
see chapter 6.3.10
There are two different procedures for the assignment of inputs. Both variants are
locked against each other to give the user maximum flexibility.
The internal input status shows the logic condition of the digital inputs which are
internally set for processing. It is unimportant, whether the external terminals are
active or not. If an input is set, the appropriate decimal value according to the table
under 6.3.8 is output. If several inputs are set, then the sum of the decimal values is
output.
With di.9 the reset input is defined according to the table under 6.3.8. If the reset input
shall react to an edge, one or several of the reset inputs defined with di.9 can be
switched to edge evaluation with di.10.
6.3.9 Input Status
(ru.22)
6.3.10 Reset/Input
Selection and
Edge Evaluation
(di.9 / di.10)
