Hardware Control Cards
3.1.5 Analog inputs
Connect unused analog inputs to common, to prevent set value fluctuations!
*) Connect potential equalizing line only
if a potential difference of > 30 V exists
between the controls.
Control card GENERAL:
Control card BASIC:
Internal analog
set-point setting
External analog
set-point setting
Internal analog
set-point setting
External analog
set-point setting
X2A
123456789
R = 3...10 kW
PE
X2A
123456789
PE
0...±10 VDC
Ri = 55 kW
+
*
178
R = 3...10 kW
PE
5
22
X2A
15 8 22
PE
7
X2A
+
0...±10 VDC
Ri = 30 kΩ
