3.5.4 Dimensions liquid cooler installation version

300

340

935

12,5

353,5

80

960

36,5

230

40

b

A

Housing P

A Distance between liquid connections

B Accessories for hose connecting piece (=> Connections to the coolant)

Weight 96 kg

Dimensions All dimensions in mm

Figure 5: Dimensions liquid cooler built-in version

44

DIMENSIONS AND WEIGHTS
