4.2.2 Liquid cooling
The liquid coolers are designed for the connection to an available cooling system.
The dissipation of the power loss must be ensured by the machine builder.
In order to avoid moisture condensation, the minimum inlet temperature may not
decrease the ambient temperature.
No aggressive coolant shall be used.
Measures against contamination and calcination must be done externally.
4.2.3 Connection of the liquid cooling to the cooling system
The connection to the cooling system can occur as closed or open cooling circuit.
The connection to a closed cycle cooling circuit is recommended, because the dan-
gerofcontaminationofcoolantissignicantlylower.
Preferably also a monitoring of the pH value of the coolant should be installed.
Pay attention to a corresponding cable cross section at required equipotential bond-
ing in order to avoid electro-chemical procedures.
Other elements in the cooling circuit such as pumps, shut-off valves, ventilation etc.
must be added according to the cooling system and the local conditions.
Payattentiontouxdirectionandchecktightness!
Extrusion casting heat sink
Screw in the connecting duct according to the assembly instructions (
=>
Connections to
the coolant)
.
Theconnectiontothecoolantmustbecarriedoutwithexible,pressure-resistant
hoses and secured with clamps.
Aluminium heat sink with pressed stainless steel tubes
Connection to the cooling circuit can be made with the aid of function nuts (=>
Connections to the coolant) and the use of elastic, pressure-resistant hoses.
Volume ow meter and temperature monitoring
Theuseofvolumeowmetersaswellastemperaturemonitoringisrecom-
mended.
ATTENTION
A discontinuous mode is not recommended, this can lead to a
reduction of the service life.
The max. pressure in the cooling system may not exceed 10 bar.
ThecoolingowmustalwaysbestartedbeforestartingtheCOM-
BIVERT.
50
MECHANICAL INSTALLATION
