KEB COMBIVERT F5 - Air Cooler; Figure 9: Ventilation

4.2.1 Air cooler
• The drive converter must be mounted vertically in the control cabinet.
• The connection terminals must be located on the bottom side.
• Sufcientventilationofthedevicemustbeensuredbythesystemmanufacturer.
Legend
①
Airowdirectionthroughtheinterior
②
Airowdirectionattheheatsink
Figure 9: Ventilation
49
MECHANICAL INSTALLATION
