6.7.3 External braking resistor with overtemperature protection
=>Wiring Diagrams.
Technical data and design of non-intrinsically safe braking
resistors.
https://www.keb.de/fileadmin/media/Manuals/dr/ma_dr_braking-resis-
tors-20116737_en.pdf
6.7.4 Sub-mounted braking resistors without overtemperature protection
• Sub-mounted braking resistors are only available for liquid-cooled devices.
• Terminal PB is not available for this device version.
ATTENTION
Sub-mounted braking resistors are not suitable to convert large
amounts of regenerative energy into heat. They are intended to inter-
cept regenerative peaks.
6.8 Temperature switch braking resistor, mains and motor choke
6.8.1 General instructions
The following must be observed when wiring the temperature switches of the braking
resistor, mains and motor choke:
• All cables must be laid separately from each other.
• If the various temperature switches are connected in series, EMC interference
from the motor side can be coupled back to the input. => Wiring.
• Chapter => Wiring Diagrams contains examples of how the temperature switches
are connected to the control board.
• The used digital inputs must be parameterized to external error.
6.8.2 Parameterization of the control board
Unit series Parameter Description Function Default value
F5
di.02 digital input selection set inputs 112 I2+I2+I3
1)
di.11 I1 function external error 8192
di.12 I2 function external error 8192 external error 8192
di.13 I3 function external error 8192
F6
di.00 digital inputs logic set inputs 7 I2+I2+I3
1)
pn.30 prog. error source set inputs 7 I2+I2+I3
Table 27: Parameterization of the control board
1) Depending on the number of the used inputs.
77
ELECTRICAL INSTALLATION
