KEB COMBIVERT F5 Instructions For Use

10.4.2 Power dissipation at 4 kHz switching frequency
Total power dissipation (Pv) in kW
2,50
2,75
3,00
3,25
3,50
3,75
4,00
4,25
4,50
4,75
5,00
5,25
5,50
5,75
6,00
6,25
6,50
6,75
7,00
150 16 0 170 180 190 200 210 220 230 240 250 260 270 280 290 300
Output current (Iout) in A
Legend
690 V + 10 % 690 V 690 V - 10 %
Figure 43: Power dissipation at 4 kHz switching frequency 690V class
99
CHARACTERISTICS

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
