KEB COMBIVERT G6 - Power Unit Connection

35
Fieldbus Parameters
Parameter Id-Text Name CANSDOIndex
fb03 CAN State 0x2183
Subindex 0
Object type Variable
Data length unsigned Byte
Access Read only
Meaning Display of the CANopen slave state
Coding
0
Initialization
4
Stopped
5
Operational
127
Preoperational
Standard 0
Parameter Id-Text Name Index
fb04 LifeGuardTout.Addr 0x2184
Subindex 0
Object type Variable
Data length unsigned Long
Access Read write
Meaning DenestogetherwiththeLifeGuardTout.Datathefunction,thatisexe-
cuted once after the life guarding timeout occurred. The value consists
of the parameter address to be written and the parameter set as well
as the function code for the control board.
Coding
Bit 0…15
Index 0000h:nofunction
0001h…FFFFhaddress
Bit 16…24
Set 00h:noset
01h:Set0
02h:Set1
03h:Set2
04h:Set3
05h:Set4
06h:Set5
07h:Set6
08h:Set7
Bit 25…31
Operational 00h:nofunction
01h:Changetoreadyforopera-
tion
Standard 0101202Bh (change to ready for operation, set 0, Sy43)
