Preface
xx G6 x x x - x x x x
Control/keyboard/display (not valid at customer/special version)
A G6K-G
Open-loop without key-
board/display
0 G6-G
Open-loop without key-
board/display
B G6K-G
Open-loop with keyboard/
display
1 G6-G
Open-loop with key-
board/display
2 G6P-S SCL (Sensorless Closed Loop) without keyboard/display
3 G6P-S SCL (Sensorless Closed Loop) with keyboard/display
4 G6L-M
ASCL (Asynchronous Sensorless Closed Loop)
without keyboard/display
5 G6L-M
ASCL (Asynchronous Sensorless Closed Loop)
with keyboard/display
Switching frequency; short time current limit; overcurrent cut-off
(not valid at customer/special version)
0 2 kHz 125 % 150 % 1 4 kHz 125 % 150 %
2 8 kHz 125 % 150 % 3 16 kHz 125 % 150 %
4 2 kHz 150 % 180 % 5 4 kHz 150 % 180 %
6 8 kHz 150 % 180 % 7 16 kHz 150 % 180 %
8 2 kHz 180 % 216 % 9 4 kHz 180 % 216 %
A 8 kHz 180 % 216 % B 16 kHz 180 % 216 %
Voltage, connection
0 1-phase 230 V AC/DC 3 3-phase 400 V AC/DC
1 3-phase 230 V AC/DC 5 400 V DC
2 1/3-phase 230 V AC/DC 6 1-phase 230 V AC
A-Z Customer-/specialversion(rmwareanddownload)
Housing type A, B, C, E
Variants
0
without lter, without braking tran-
sistor, without safety function STO
A like 0 with STO H
like A with
f=0Hz
1
withoutlter,withbrakingtransistor,
without safety function STO
B like 1 with STO I
like B with
f=0Hz
2
internal lter; without braking tran-
sistor, without safety function STO
C like 2 with STO K
like C with
f=0Hz
3
internallter,withbrakingtransistor,
without safety function STO
D like 3 with STO L
like D with
f=0Hz
Control type
C Analog/digital (standard)
D CAN
®
1
E IO-Link
®
2
F EtherCAT
®
3
G PROFINET
®
4
H reserved for POWERLINK
I VARAN
G6 unit type
Inverter size
