Parameter sets
© KEB, 2015-07 COMBIVERT R6-N Page3.7 - 7
3
10
Fr.04 Parameter set setting
Parameter Fr.04 can be written via keyboard and via bus. The desired parameter set (0… 7) is directly preset
as value and activated by pressing Enter.
Fr.07 Parameter set Input selection
The setting for the terminal strip can be done binary-coded or input-coded. The inputs are determined with
parameter Fr.07. Maximally 3 inputs should be programmed to set source at binary-coded set source, in order
to avoid set source errors.
Fr.10:Parameter set input selection
Bit Value Input Terminal
0 1
1)
ST (prog. input „control release/reset“) X2A.12
1 2 RST (prog. input „reset“) no
2 4 F (prog. input „forward“) no
3 8 R (prog. input „reverse“) no
4 16 I1 (prog. input 1) X2A.13
5 32 I2 prog. input 2) X2A.14
6 64 I3 (prog. input 3) X2A.15
7 128
2)
I4 (prog. input 4) X2A.16
8 256 IA (internal input A) no
9 512 IB (internal input B) no
10 1024 IC (internal input C) no
11 2048 ID (internal input D) no
1)
Input ST is assigned by hardware with the function „control release“. Further functions can only be ad-
justed additionally.
2)
The input I4 is connected by hardware with the master- / slave control. Further functions can only be
adjusted additionally.
Example
Binary-coded set selection
At binary codedsetselection:
- - maximally 3 of the internal or external inputs may be programmed to set selection (2
3
=8 sets) to avoid
set selection errors.
- if the value of the inputs programmed for set selection is ascending
(ID>IC>IB>IA>I4>I3>I2>I1>R>F>RST>ST)
