Operating and appliance data

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.25 Output terminal state 0219h ro - - 0 255 1 - -

Displayofthecurrentlysetexternalandinternaldigitaloutputs.Accordingtofollowingtableaspecicdecimal

value is output for each digital output. If several outputs are set, the sum of the decimal values is displayed.

Bit Decimal

value

Output Terminal

0 1 O1 (transistor output 1) X2A.19

1 2 O2 (transistor output 2) X2A.20

2 4 R1 (relay RLA,RLB,RLC) X2A.24...26

3 8 R2 (relay FLA,FLB,FLC) X2A.27...29

4 16 OA (internal output A) no

5 32 OB (internal output B) no

6 64 OC (internal output C) no

7 128 OD (internal output D) no

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.26 Active parameter set 021Ah ro - - 0 7 1 - -

The KEB COMBIVERT can have access to 8 parameter sets (0-7). Through programming the inverter can

change parameter sets autonomously and can thus start different modes of operation. This parameter dis-

plays the actual parameter set. Independent of it another parameter set can be edited by bus (also see

chapter 3.7).

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.33 ANOUT1 / pre ampl.

disp.

0221h ro - - -400 400 0,1 % -

This parameter displays the value of the analog signal ANOUT1 in percent before passing the characteristic

amplier(alsosee3.3„Analogoutputs“).

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.34 ANOUT1 / post ampl. disp. 0222h ro - - -100 100 0,1 % -

This parameter displays the value of the signal given out at analog output ANOUT1 (terminal X2A.21) in

percent. A value of 0...±115 % corresponds to an output signal of 0...±11,5 V (also see chapt. 3.3 „Analog

outputs“).

Parameter Addr. R PG E Min. value Max. value Res. [?] Default

ru.38 Power module tempera-

ture

0226h ro - - 0 100 1 °C -

ru.38 displays the actual power module temperature. On exceeding the maximum power module temperature

the modulation is switched off and error E.OH is displayed. Message E.nOH is displayed after the cooling

period. The error can be reset now.
