4.3.2 Using iOS Devices
1. Make sure your mobile device is connected to the network you want to onboard your
speaker to.
2. Launch and login to the KEF Connect App on your mobile device.
3. Select “LS50 Wireless II” under “Speakers nearby”.
The speakers with the warning sign (
) are not set up yet. Select the speakers with
this warning mark to get them “onboarded”.
The speakers with the check mark (
) are ready for use. If the speakers are
connected to the network via a LAN cable. Select the speakers with this check mark.
4. Select your local Wi-Fi network.
You may rename the speakers by tapping “Speaker name”.
5. The onboarding process will be done automatically. Tap “Done” when the process is
completed.
[Step 3–5]
• The Wi-Fi icon on the top panel of the Primary Speaker is solid white when
the speakers are successfully connected.
• After successful connection, you may be prompted if there is a new firmware
update available. Follow the instructions in the KEF Connect App to complete
the update process.

KEF LS50 Wireless II Specifications

General

Max SPL	108dB
Wired Outputs	Subwoofer output
Drivers	Uni-Q Driver Array
Type	Wireless Speaker System
Connectivity	Wi-Fi, Bluetooth
Wi-Fi	802.11a/b/g/n/ac
Wireless Streaming Features	AirPlay 2, Google Chromecast
Streaming Services	Spotify Connect, Tidal Connect, Amazon Music, Qobuz, Deezer
Inputs	HDMI eARC, Optical, USB Type A
Drive Units	5.25" Aluminium woofer, 1" Aluminium dome tweeter
Woofer	5.25" Aluminum
Tweeter	1" Aluminium dome
Dimensions	305 x 200 x 311 mm (H x W x D)
Finish Options	Carbon Black, Mineral White
Weight	10 kg per speaker
