KEF LS50 Wireless II User Manual

41
Table of ContentsSetting UpWi-Fi StreamingUsing KEF Connect AppFAQ and Troubleshooting
11.2 Selecting Coaxial Mode
• In the KEF Connect App, tap the Coaxial button (CX) to switch to Coaxial mode.
• Alternatively, press the source button on the top panel of the Primary Speaker;
• Or, press the source button on the remote control.
• The CX icon is lit when Coaxial mode is selected.
You can assign Coaxial mode as a second wake-up source to turn on the
speakers automatically when there is audio input through the coaxial connection.
See chapter “Power Saver – Second Wake-Up Source.
11.3 Playback Controls
All playback controls (except adjusting volume) must be done on the connected device.
The volume can also be adjusted on the top panel or remote control.

KEF LS50 Wireless II Specifications

General

Max SPL	108dB
Wired Outputs	Subwoofer output
Drivers	Uni-Q Driver Array
Type	Wireless Speaker System
Connectivity	Wi-Fi, Bluetooth
Wi-Fi	802.11a/b/g/n/ac
Wireless Streaming Features	AirPlay 2, Google Chromecast
Streaming Services	Spotify Connect, Tidal Connect, Amazon Music, Qobuz, Deezer
Inputs	HDMI eARC, Optical, USB Type A
Drive Units	5.25" Aluminium woofer, 1" Aluminium dome tweeter
Woofer	5.25" Aluminum
Tweeter	1" Aluminium dome
Dimensions	305 x 200 x 311 mm (H x W x D)
Finish Options	Carbon Black, Mineral White
Weight	10 kg per speaker
