Test 403.3 — NON INV BEX2

Bank VAC

Inputs Open

Expected Value <none speciﬁed>

Limits <none speciﬁed>

Fault Message <none>

Description This phase resets the circuit to a known state and turns the waveform sig-

nal off. Subsequent tests require that the A/D be in the normal operating

mode.

Bit patterns

Bit pattern Register

87654321

—U106—

011v0011

87654321

—U109—

11011111

87654321

—U134—

1v01000v

—U130—

10011101

87654321

—U121—

01110000

ACDC_STB

MUX_STB

IC pins: Q8=11, Q7=12, Q6=13, Q5=14, Q4=7, Q3=6, Q2=5, Q1=4

Troubleshooting 2-51
