Keithley 2001 Calibration Manual

Calibration Command Reference
3-9
3.3.10 :DC
(CALibration:PROTected):DC
The :DC commands perform comprehensive (user) calibration. Table 3-3 summarizes these
comprehensive calibration commands.
:ZERO
(:CALibration:PROTected:DC):ZERO
Purpose To perform short-circuit comprehensive calibration.
Format :cal:prot:dc:zero
Parameters None
Description :ZERO performs the short-circuit calibration step in the comprehensive calibration proce-
dure. A low-thermal short (Model 8610) must be connected to the input jacks before send-
ing this command.
Programming example 10 OUTPUT 716; “CAL:PROT:DC:ZERO” ! Do short-circuit cal.
:LOW
(:CALibration:PROTected:DC):LOW
Purpose To program the +2V DC comprehensive calibration step.
Format :cal:prot:dc:low <cal_voltage>
Parameters <Cal_voltage> = 1.0 to 2.0 [V]
Description :LOW programs the +2V DC comprehensive calibration step. The allowable range of the
calibration voltage parameter is from 1.0 to 2.0V, but 2V is recommended for best results.
Programming example 10 OUTPUT 716; “:CAL:PROT:DC:LOW 2” ! Program 2V step.
Table 3-3
Comprehensive calibration commands
Command Description
:CALibration
:PROTected
:DC
:ZERO
:LOW <value>
:HIGH <value>
:LOHM <value>
:HOHM <value>
:OPEN
Calculate
User calibration subsystem.
Low-thermal short calibration step.
+2V DC calibration step.
+20V DC calibration step.
20k¾ calibration step.
1M¾ calibration step.
Open circuit calibration step.
DC cal constants.

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
