AC AMPS (cont’d)
ACI READING RATES
3,4
READINGS/SECOND WITH
MEASUREMENT DEFAULT READINGS/SECOND TO MEMORY READINGS/SECOND TO IEEE-488 TIME STAMP TO IEEE-488
NPLC APERTURE BITS DIGITS Auto Zero Off Auto Zero On Auto Zero Off Auto Zero On Auto Zero Off Auto Zero On
10 167 ms (200 ms) 28 6
1
⁄2 6 (5.1) 2 (1.7) 6 (4.9) 2 (1.6) 6 (4.8) 2 (1.6)
2 33.4 ms (40 ms) 26 5
1
⁄2 30 (25) 9 (7.9) 28 (23) 9 (7.6) 27 (22) 9 (7.5)
1 16.7 ms (20 ms) 25 5
1
⁄2 57 (48) 39 (35) 53 (45) 37 (33) 49 (41) 34 (30)
0.1 1.67 ms (2 ms) 21 5
1
⁄2 157 (136) 70 (70) 123 (123) 62 (62) 107 (107) 56 (53)
0.01 167
μ
s (167
μ
s) 16 4
1
⁄2 156 (136) 70 (70) 140 (140) 63 (63) 113 (113) 56 (56)
0.01
6
167
μ
s (167
μ
s) 16 4
1
⁄2 2000 (2000) 2000 (2000)
SETTLING CHARACTERISTICS: <300ms to 1% of step change
<450ms to 0.1% of step change
<500ms to 0.01% of step change
AUTORANGING: Autoranges up at 105% of range, down at 10% of range.
AVERAGE ACI MEASUREMENT
Rms specifications apply for 10% to 100% of range.
TEMPERATURE (RTD)
RESO- 4-WIRE ACCURACY
3
RANGE LUTION 1 Hour
2
90 Days 1 Year 2 Years
–100
°
to +100
°
C 0.001
°
C
±
0.005
°
C
±
0.05
°
C
±
0.08
°
C
±
0.12
°
C
–200
°
to +630
°
C 0.001
°
C
±
0.005
°
C
±
0.12
°
C
±
0.14
°
C
±
0.18
°
C
–212
°
to +180
°
F 0.001
°
F
±
0.009
°
F
±
0.09
°
F
±
0.15
°
F
±
0.22
°
F
–360
°
to +1102
°
F 0.001
°
F
±
0.009
°
F
±
0.15
°
F
±
0.18
°
F
±
0.33
°
F
RTD TYPE: 100
Ω
platinum; DIN 43 760 or IPTS-68, alpha 0.00385, 0.00390,
0.003916, or 0.00392, 4-wire.
MAXIMUM LEAD RESISTANCE (each lead): 12
Ω
(to achieve rated accuracy).
SENSOR CURRENT: 1mA (pulsed).
COMMON MODE REJECTION: <0.005
°
C/V at DC, 50Hz, 60Hz and 400Hz,
(100
Ω
imbalance, LO driven).
TEMPERATURE COEFFICIENT:
±
(0.0013% + 0.005
°
C)/
°
C or
±
(0.0013% + 0.01
°
F)/
°
C outside TCAL
±
5
°
C.
RTD TEMPERATURE READING RATES
1
(2- or 4-Wire)
READINGS or READINGS WITH TIME STAMP/SECOND
TO MEMORY or IEEE-488
NPLC Auto Zero Off Auto Zero On
10 1 (1) 1 (1)
2 5 (4.3) 4 (3.6)
1 7 (6.5) 6 (5.5)
0.1 12 (10.8) 9 (9)
0.01 12 (12) 10 (10)
HIGH CREST FACTOR ADDITIONAL ERROR
±
(% of reading)
Applies to rms measurements.
CREST FACTOR 1 – 2 2 – 3 3 – 4 4 – 5
ADDITIONAL ERROR 0 0.1 0.2 0.4
AC AMPS NOTES
1. Specifications apply for sinewave input, AC+DC coupling, 1 power line cycle, digital filter off,
following 55 minute warm-up.
2. Add 0.005% of range uncertainty for current above 0.5A rms for self-heating.
3. Typical values.
4. For DELAY=0, digital filter off, display off, internal trigger. Aperture is reciprocal of line
frequency. These rates are for 60Hz and (50Hz).
5. Actual maximum voltage burden = (maximum voltage burden) × (I
MEASURED/IFULL SCALE).
6. In burst mode, display off. Burst mode requires Auto Zero refresh (by changing resolution
or measurement function) once every 24 hours.
TEMPERATURE NOTES
1. Typical speeds for Auto Zero on. For DELAY=0, digital filter off, display off, internal
trigger. Rates are for 60Hz and (50Hz).
2. For ambient temperature
±
1
°
C, measured temperature
±
10
°
C, 10-reading digital filter.
3. Excluding probe errors. T
CAL
±
5
°
C.
4. Relative to external 0
°
C reference junction; exclusive of thermocouple errors. Junction
temperature may be external. Applies for 90 days, 1 year or 2 years, T
CAL
±
5
°
C.
TEMPERATURE (Thermocouple)
THERMO-
COUPLE DEFAULT
TYPE RANGE RESOLUTION ACCURACY
4
J –200
°
to + 760
°
C 0.1
°
C
±
0.5
°
C
K –200
°
to +1372
°
C 0.1
°
C
±
0.5
°
C
T –200
°
to + 400
°
C 0.1
°
C
±
0.5
°
C
E –200
°
to +1000
°
C 0.1
°
C
±
0.6
°
C
R0
°
to +1768
°
C1
°
C
±
3
°
C
S0
°
to +1768
°
C1
°
C
±
3
°
C
B +350
°
to +1820
°
C1
°
C
±
5
°
C
TC TEMPERATURE READING RATES
1
READINGS/SECOND
READINGS/SECOND READINGS/SECOND WITH TIME STAMP
TO MEMORY TO IEEE-488 TO IEEE-488
Auto Zero Auto Zero Auto Zero
NPLC Off On Off On Off On
10 6 (5.1) 2 (1.7) 4 (3.4) 2 (1.4) 4 (3.4) 2 (1.4)
2 30 (25) 9 (7.6) 28 (23) 9 (7.3) 27 (22) 8 (7.2)
1 57 (48) 43 (37) 53 (45) 40 (32) 49 (41) 37 (30)
0.1 139 (139) 95 (95) 126 (123) 85 (84) 99 (99) 72 (72)
0.01 177 (177) 98 (98) 156 (156) 87 (87) 119 (119) 73 (73)
FREQUENCY COUNTER
FREQUENCY/PERIOD INPUT CHARACTERISTICS AND ACCURACY
90 Days, 1 Year, or 2 Years
FREQUENCY PERIOD DEFAULT MINIMUM SIGNAL LEVEL MAXIMUM TRIGGER ACCURACY
RANGE
1
RANGE RESOLUTION 1Hz–1MHz 1–5MHz 5–15MHz INPUT LEVEL
±
(% of reading)
AC Voltage Input 1Hz–15 MHz 67 ns – 1 s 5 digits 60 mV 60 mV 350 mV 1100 V pk
1
0–600V 0.03
AC Current Input 1Hz– 1 MHz 1
μ
s – 1 s 5 digits 150
μ
A 1 A pk 0–600mA 0.03
MEASUREMENT TECHNIQUE: Unique pulse count/time count at overflow.
TIME BASE: 7.68MHz
±
0.01%, 0
°
C to 55
°
C.
READING TIME: 420ms maximum.
TRIGGER LEVEL ADJUSTMENT: Trigger level is adjustable in 0.5% of range steps
to
±
60% of range in real-time using the up and down range buttons.
FREQUENCY RANGING: Autoranging from Hz to MHz.
FREQUENCY COUPLING: AC + DC or AC only.
FREQUENCY NOTES
1. Subject to 2 × 10
7
V•Hz product (for inputs above 20V).
