Troubleshooting

2-69

Components U403, U430, U433, and associated components.

Bit patterns

Test 400.5 — DAC output set to 4.48V

Type

Pass/Fail

Fault message DAC output not +4.48V

Description This test is the same as test 400.1 except that U433 (DAC B) is conﬁgured for a 4.48V output.

Drawing reference Analog Board; 2002-100

Components U403, U430, U433, and associated components.

Bit patterns

Bit pattern* Register

—U400—

01011011

—U811—

00001101

—U224—

00010111

—U432—

10111000

—U810—

00000011

—U206—

01110000

—U203—

10001110

—U411—

11111011

—U809—

11100111

—U207—

11001111

—U221—

11101001

—U406—

00001100

AD_STB

MUX_STB

R1_STB

R2_STB

*Bits associated with register IC terminals as follows:

QQQQQQQQ

87654321 87654321 87654321 87654321

IC pins: Q8=11, Q7=12, Q6=13, Q5=14, Q4=7, Q3=6, Q2=5, Q1=4.
