Keithley 2002 Repair Manual

4
Replaceable Parts
4-1
4.1 Introduction
This section contains replacement parts information and
component layout drawings for the Model 2002.
4.2 Parts lists
The following parts lists for the Model 2002 are shown in Ta-
bles 4-1 to 4-5. For part numbers to the various mechanical
parts and assemblies, use the miscellaneous parts list (Table
4-5) and the assembly drawings provided at the end of Sec-
tion 3.
4.3 Ordering information
To place an order, or to obtain information concerning re-
placement parts, contact your Keithley representative or the
factory (see inside front cover for addresses). When ordering
parts, be sure to include the following information:
• Instrument model number (Model 2002)
• Instrument serial number
• Part description
• Component designation (if applicable)
• Keithley part number
To facilitate repairs, complete circuit boards are available.
Contact the Repair Department (see below) for pricing and
availability.
4.4 Factory service
If the instrument is to be returned to Keithley Instruments for
repair, perform the following:
1. Call the Repair Department at 1-800-552-1115 for a Re-
turn Material Authorization (RMA) number.
2. Complete the service form at the back of this manual,
and include it with the instrument.
3. Carefully pack the instrument in the original packing
carton.
4. Write ATTENTION REPAIR DEPARTMENT and the
RMA number on the shipping label.
4.5 Component layouts
The component layouts are provided in the following pages:
A/D Converter Board: 2002-160
Display Board: 2002-110
Analog Board: 2002-100
Digital Board: 2002-140
