Troubleshooting

2-85

Bit patterns

Test 407.3 — Front end 750V range

Type

Pass/Fail

Fault message

Front end 750V range

Description

REFHI is tied to pin 1 of U420 and buffered to form BUFF. BUFF through R493 is tied to NET1,

pin 1 (R488). U428 connects R489 in parallel to the bottom leg of the NET1 divider. The divided

voltage (/500), R488 pin 4 is tied to the input buffer Q418 and U423 through U428 and Q422.

The buffered signal AMP IN is tied to the FWR, and, being positive, follows the non-inverting,

X10 path R452, Q413, Q411, U417, R453, U410, Q404, and U419 to pin 12 of U414. The out-

put of U414 is tied to the A/D buffer through buffer U403, R434, R462, and U222. The A/D buff-

er is conﬁgured for X1 gain.

Drawing reference

Analog Board; 2002-100

Components

Q418, U410, U417, U419, U420, U423, and associated components.

Bit patterns

Bit pattern* Register

—U400—

01110100

—U811—

00001101

—U224—

00010111

—U432—

10000000

—U810—

00000011

—U206—

01110000

—U203—

10001110

—U411—

11111111

—U809—

11100111

—U207—

11001111

—U221—

11101001

—U406—

01101110

AD_STB

MUX_STB

R1_STB

R2_STB

*Bits associated with register IC terminals as follows:

QQQQQQQQ

87654321 87654321 87654321 87654321

IC pins: Q8=11, Q7=12, Q6=13, Q5=14, Q4=7, Q3=6, Q2=5, Q1=4.
