• BYPASS: Enables or disables bypassing the first item in the scan. Related command:
scan.bypass (on page 11-314).
• MODE: Sets the scan.mode value to one of the following:
▪ OPEN_ALL, which is equivalent to scan.MODE_OPEN_ALL or 0 (default setting)
▪ OPEN_SELECT, which is equivalent to scan.MODE_OPEN_SELECTIVE or 1
▪ FIXED_ABR, which is equivalent to scan.MODE_FIXED_ABR or 2
Related command: scan.mode (on page 11-321)
• MEAS_CNT: Sets the measure count value. Related command: scan.measurecount (on page
11-320)
• SCAN_CNT: Sets the scan count value. Related command: scan.scancount (on page 11-325)
DMM key configuration
Press the CONFIG key and then the DMM key to open a DMM attribute menu for the active function.
For example, if the DCV function is active, pressing the CONFIG key and then the DMM key opens
the DC VOLT ATTR menu.
Each function only has access to the applicable attributes for that function. Brief definitions of the
available attributes are contained in the following paragraphs. Refer to the appropriate command for
additional attribute information in the TSP commands (on page 11-8).
The DMM ATTR menu contains:
APERTURE: Configures the aperture setting for the active DMM function in seconds. Related
command: dmm.aperture (on page 11-145).
AUTODELAY: Configures the autodelay setting for the active DMM function. Related command:
dmm.autodelay (on page 11-148).
AUTORANGE: Configures the autorange setting for the DMM. Related command: dmm.autorange
(on page 11-149).
AUTOZERO: Configures the autozero setting for the DMM, which periodically measures internal
voltages to help maintain the stability and accuracy of the instrument over time and changes in
temperature. Related command: dmm.autozero (on page 11-150). Also see Autozero (on page 4-3).
DBREF: Configures the dB reference setting for the DMM in volts. Related command:
dmm.dbreference (on page 11-170).
DETECTBW: Configures the detector bandwidth setting for the selected DMM function. For more
information, see Bandwidth (on page 4-59). Related command: dmm.detectorbandwidth (on page 11-
171).
DIGITS: Configures the display digits setting for the selected DMM function. For more information,
see Change the display resolution (on page 4-6). Related command: dmm.displaydigits (on page 11-
172).
DRYCIRCUIT: Configures the dry circuit setting for the selected DMM function. Related command:
dmm.drycircuit (on page 11-173).
FILTER: Opens the FILTER menu for the selected DMM function. See FILTER key configuration (on
page 3-21).
FUNC: Displays a menu that allows you to scroll through the available DMM functions. Use the
navigation wheel or CURSOR keys to scroll the menu options and press ENTER when the function
you want to select is highlighted. Related command: dmm.func (on page 11-179).
INPUTDIV: Enables or disables the 10 M input divider. Related command: dmm.inputdivider (on
page 11-182).
