Keithley 6517A User Manual

Front Panel Operation
2-109
LIMITS
LIMIT-SET-1
CONTROL
LOLIM1
HILIM1
LIMIT-SET-2
CONTROL
LOLIM2
HILIM2
STROBE-CONTROL
PASS-PATTERN
Limits menu:
Limit-Set-1 menu:
Enable/disable limit set #1.
Set value of low limit #1.
Set value of high limit #1.
Limit-Set-2 menu:
Enable/disable limit set #2.
Set value of low limit #2.
Set value of high limit #2.
Enable/disable limit strobe signal of digital output #4 when trigger occurs.
Specify patterns on digital outputs to signify limit pass.
STATUS-MSG Enable/disable status message mode.
GENERAL
DIGOUT
STATE
LOGIC-SENSE
SERIAL #
A/D-CONTROLS
LINE-SYNC
DATA-STAMP
LIMIT-CTRL
TIMESTAMP
TYPE
RELATIVE-TIME
REAL-TIME
RESET-TIME
RESET-RDG#
DISPLAY
NUMERIC-FORMAT
DECIMAL-CHAR
CLOCK
TIME
DATE
FORMAT
General menu:
Digital output menu:
Check/change states of digital output lines.
Check/change sense of digital output lines.
Display serial number, memory option SCPI version, and firmware revisions.
A/D menu:
Enable/disable line synchronization. Also displays power line frequency.
Configure A/D to measure additional inputs (humidity and external temperature).
Enable/disable A/D hardware limit.
Configure timestamp:
Check or change type.
Reference timestamp to relative time.
Reference timestamp to real time.
Reset relative timestamp to zero.
Reset reading number to zero.
Display menu:
Select measurement units (engineering or scientific).
Select period or comma as decimal point.
Clock menu:
Check or set time of day.
Check or set date.
Select clock format: (12-hour or 24-hour format).
Table 2-29 (cont.)
MAIN MENU STRUCTURE
