Keithley 6517A User Manual

IEEE-488 Reference
3-42
SCPI Command Summary
Tables 3-4 through 3-16 summarize the commands for each SCPI subsystem.
General notes:
• Brackets ([ ]) are used to denote optional character sets. These optional characters do not have to be included in the program
message. Do not use brackets in the program message.
• Angle brackets (< >) are used to indicate parameter type. Do not use angle brackets in the program message.
• The Boolean parameter (<b>) is used to enable or disable an instrument operation. 1 or ON enables the operation and 0 or
OFF disables the operation.
• Upper case characters indicate the short-form version for each command word.
• Default Parameter - Listed parameters are both the *RST and :SYSTem:PRESet defaults, unless noted otherwise. Param-
eter notes are located at the end of each table.
• SCPI - A check mark (˚) indicates that the command and its parameters are SCPI confirmed. An unmarked command in-
dicates that it is non-SCPI. SCPI confirmed commands that use one or more non-SCPI parameters are explained by notes.
Table 3-4
CALCulate command summary
Command Description
Default
parameter
SCPI Ref.
:CALCulate[1]
:FORMat <name>
:FORMat?
:KMATh
:MA0Factor <NRf>
:MA0Factor?
:MA1Factor <NRf>
:MA1Factor?
:MA2Factor <NRf>
:MA2Factor?
:PERCent <NRf>
:PERCent?
:REFerence <NRf>
:REFerence?
:STATe <b>
:STATe?
:DATA
[:LATest]?
:FRESh?
:IMMediate
Subsystem to control CALC1:
Select math format (NONE, POLynomial, PERCent, RATio,
DEViation, PDEViation, LOG10).
Query math format.
Path to control math calculations:
Set “a0” for POLynomial (-9.999999e30 to +9.999999e30).
Query “a0” factor.
Set “a1” for POLynomial (-9.999999e20 to +9.999999e20).
Query “a1” factor.
Set “a2” for POLynominal (-9.999999e30 to +9.999999e30).
Query “a2” factor.
Specify target value for percent calc
(-9.999999e35 to +9.999999e35
Query target value.
Set reference value for Ratio, Deviation and % Deviation
(-9.999999e35 to +9.999999e35).
Query reference value.
Enable or disable calculation.
Query state of math function.
Path to read math result of calculation.
Return last reading.
Return new reading.
Recalculate input data.
Polynomial
0
1
0
1
1
(Note)
√
√
√
√
√
√
√
√
√
3.13.1
:CALCulate2
:FORMat <name>
:FORMat?
:STATe <b>
:STATe?
:IMMediate
:DATA?
Subsystem to control CALC 2:
Select math format: (MEAN, SDEViation, MAXimum,
MINimum, PKPK, or NONE).
Query math format.
Enable or disable calculation.
Query state of math function.
Recalculate raw input data in buffer.
Read math result of CALC 2.
NONE
(Note)
√
√
√
√
√
√
√
3.13.2
