IEEE-488 Reference
3-40
:MEASure[:<function>]?
where: <function> =
VOL
T
age[:DC]
V
olts function
CURRent[:DC]
Amps function
RESistance
Ohms function
CHARge
Coulombs function
This command combines all of the other signal oriented measurement commands to perform a
“one-shot” measurement and acquire the reading.
When this command is sent, the follo
wing commands are ex
ecuted in the order that they are pre-
sented.
