Keithley 6517A User Manual

IEEE-488 Reference
3-47
:VOLTage[:DC]
:APERture <n>
:AUTO <b>
:AUTO ONCE
:AUTO?
:APERture?
:NPLCycles <n>
:AUTO <b>
:AUTO ONCE
:AUTO?
:NPLCycles?
:RANGe
[:UPPer] <n>
[:UPPer]?
:AUTO <b>
:AUTO ONCE
:ULIMit <n>
:ULIMit?
:LLIMit <n>
:LLIMit?
:AUTO?
:REFerence <n>
:STATe <b>
:STATe?
:ACQuire
:REFerence?
:DIGits <n>
:AUTO <b>
:AUTO ONCE
:AUTO?
:DIGits?
:AVERage
:TYPE <name>
:TYPE?
:TCONtrol <name>
:TCONtrol?
:COUNt <n>
:COUNt?
:ADVanced
:NTOLerance <n>
:NTOLerance?
[:STATe] <b>
[:STATe]?
:MEDian
[:STATe] <b>
[:STATe]?
:RANK <NRf>
:RANK?
:GUARd <b>
:GUARd?
:XFEedback <b>
:XFEedback
Path to configure volts:
Set integration rate in seconds (166.67e-6 to 200e-3).
Enable or disable auto aperture.
Enable and then disable auto aperture.
Query auto aperture.
Query aperture (integration rate).
Set integration rate (line cycles; (0.01 to 10).
Enable or disable auto NPLC.
Enable and then disable auto NPLC.
Query auto line cycle integration.
Query line cycle integration rate.
Path to configure measurement range:
Select range (0 to 210).
Query range.
Enable or disable auto range.
Set range based on present input signal.
Set upper limit for auto range (0 to 210).
Query upper limit.
Set lower limit for auto range (0 to 210).
Query lower limit.
Query auto range.
Specify reference (-210 to +210).
Enable or disable reference.
Query state of reference (0 or 1).
Use input signal as reference.
Query reference value.
Specify measurement resolution (4 to 7).
Enable or disable auto resolution.
Enable and then disable auto resolution.
Query auto resolution.
Query resolution.
Path to control the average filter.
Select filter type (NONE, SCALar, ADVanced).
Query filter type.
Select filter type: (MOVing or REPeat).
Query filter type.
Specify filter count (1 to 100).
Query filter count.
Path to configure and control advanced filter.
Specify noise tolerance level (0 to 100%).
Query noise tolerance level.
Enable or disable digital filter.
Query state of digital filter.
Path to control the median filter:
Enable or disable median filter.
Query state of median filter.
Specify rank for median filter (1 to 5).
Query rank.
Enable or disable guard.
Query state of guard.
Enable or disable external feedback.
Query state of external feedback.
(Note 1)
OFF
1
OFF
200
(Note 4)
200
2
0
OFF
6
SCALar
(Note 3)
10
1
OFF
ON
1
OFF
OFF
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
3.19.4
3.19.5
3.19.6
3.19.7
3.19.9
3.19.10
3.19.11
3.19.13
3.19.15
Table 3-10 (Continued)
SENSe command summary
Command Description
Default
parameter SCPI Ref.
