2400 Series SourceMeter

User’s Manual Range, Digits, Speed, and Filters 7-13

Filter programming example

Table 7-5 summarizes the command sequence to program ﬁlter aspects as follows:

• Filter type: moving

• Filter count: 20

• Filter state: on

Table 7-5

Filter programming example

Command Description

*RST

:SENS:AVER:TCON MOV

:SENS:AVER:COUN 20

:SENS:AVER ON

Restore RST defaults.

Moving average type ﬁlter.

Filter count = 20.

Enable ﬁlter.
