Series 2600 System SourceMeters Reference Manual Buffer (Data Store) 7-3

Return to Section 7 topics 2600S-901-01 Rev. A / May 2006

Buffer configuration menu

The various buffer configuration menu items include:

• COUNT: Sets number of readings to store (1 to 110,000). NOTE: All of the

buffers share a common memory area. Therefore, to store as many as

110,000 readings, the source values and timestamps must not be enabled

for any of the buffers.

• CHANA_BUFF: Configures Channel A buffer.

– DEST: Sets data storage destination (Buffer 1, Buffer 2, or NONE).

– BUFFER1: Configure buffer 1.

• CLEAR: Clear buffer (YES or NO).

• ELEMENTS: Enable (ON) or disable (OFF) data storage elements;

SRC-VAL (source value) or TSTAMP (time stamp).

– BUFFER2: Configure buffer 2.

• CLEAR: Clear buffer (YES or NO).

• ELEMENTS: Enable (ON) or disable (OFF) data storage elements;

SRC-VAL (source value) or TSTAMP (time stamp).

• CHANB_BUFF: Configures Channel B buffer (Model 2602/2612 only).

– DEST: Sets data storage destination (Buffer 1, Buffer 2, or NONE).

– BUFFER1: Configure buffer 1.

• CLEAR: Clear buffer (YES or NO).

• ELEMENTS: Enable (ON) or disable (OFF) data storage elements;

SRC-VAL (source value) or TSTAMP (time stamp).

– BUFFER2: Configure buffer 2.

• CLEAR: Clear buffer (YES or NO).

• ELEMENTS: Enable (ON) or disable (OFF) data storage elements;

SRC-VAL (source value) or TSTAMP (time stamp).

Storing readings

NOTE Model 2601/2611 buffer configuration menu items are

the same as covered above except for channel

selection.

NOTE Pressing the Model 2602/2612 STORE key will

overwrite the destination buffer on both channels

unless NONE is selected (see above).
