Table 1-1
Main menu
Menu selection Description Reference
SAVESETUP
SAVE
RECALL
POWERON
RESET
Save/recall user and factory setups.
Save up to five user setups.
Recall user setups.
Set power-on default configuration.
Reset Series 2600 to factory defaults.
Section 1
COMMUNICATION
INTERFACE_CFG
INTERFACE_SEL
TSPLINK_CFG
Select interface, control settings.
Configure GPIB and RS-232 interfaces.
Select GPIB or RS-232 interface, or use AUTO.
Select NODE and RESET TSP-Link.
Section 11
Section 11
Section 9
TEST
KEYS
DISPLAY_PATTERNS
Perform display tests.
Test keys.
Perform display patterns tests.
Section 17
LINE-FREQ Set line frequency to 50Hz, 60Hz, or AUTO. Section 1
GENERAL
DIGOUT
BEEPER
SYSTEM-INFO
Control digital I/O, beeper, system information.
Set digital I/O bits, control write protect.
ENABLE or DISABLE beeper.
Display FIRMWARE, SERIAL#, CAL dates.
Section 10
Section 1
Section 1
1-20 Getting Started Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 1 topics
