10-12 Digital I/O Port Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 10 topics
Figure 10-4
Using Model 2611/2612 Interlock
To output stage
10kW
Rear panel
Chassis ground
Coil resistance
145W +/- 10%
-220V supply
+220V supply
INTERLOCK pin
(on DIGITAL I/O connector)
Read by firmware
Pin 24
Closing
Switch
Enables
200V
Operation
+5V
Pin 23
