Series 2600 System SourceMeters Reference Manual Getting Started 1-9
Return to Section 1 topics 2600S-901-01 Rev. A / May 2006
Bottom Row
LOAD Loads factory or user-defined scripts for execution.
RUN Runs last selected factory or user-defined scripts.
STORE Stores readings, source values, and timestamp values in one of two
internal buffers for later recall.
RECALL Recalls stored readings, source values, and timestamp values from either
of the two buffers.
TRIG Triggers readings.
MENU Accesses the main menu for saving and recalling setups, selecting
remote interface, line frequency, self-tests, serial number and beeper
control.
EXIT Cancels selection, backs out of menu structure. Also used as a LOCAL
key to take the unit out of remote.
ENTER Accepts selection, moves to next choice or exits menu.
3 Range keys:
and Selects the next higher or lower source or measure range.
AUTO Enables or disables source or measure auto range.
4 Output control and LED status indicator:
OUTPUT ON/OFF Turns source output on or off.
LED indicator Turns on when output is on.
5 Rotary knob and CURSOR keys:
When in source edit, use CURSOR keys for cursor control and then rotate the knob to
change a source or compliance value. The rotary knob can also be used to enable or
disable the source edit mode.
When in a menu, use the CURSOR keys or rotary knob for menu item cursor control.
When displaying a menu value, use the CURSOR keys for cursor control and rotate the
knob to change the value. Pressing the knob opens a menu item, or selects a menu
option or value.
6 Display annunciators (not shown):
EDIT Unit is in the source editing mode.
ERR Questionable reading or invalid cal step.
REM Unit in remote mode.
TALK Unit addressed to talk.
LSTN Unit addressed to listen.
SRQ Service request.
REL Relative mode enabled.
FILT Analog filter or Averaging filter is enabled.
AUTO Auto source or measure range selected.
ARM Unit armed and ready to run.
TRIG External triggering selected.
* (asterisk) Readings being stored in buffer.
