Series 2600 System SourceMeters Reference Manual Instrument Control Library 12-107
Return to Section 12 topics 2600S-901-01 Rev. A / May 2006
status.operation.*
status.operation.condition
status.operation.enable
status.operation.event
status.operation.ntr
status.operation.ptr
* = condition, enable, event, ntr or ptr
Attribute Operation event status register set.
Usage Reads condition, enable, event, NTR and PTR registers:
operreg = status.operation.condition
operreg = status.operation.enable
operreg = status.operation.event
operreg = status.operation.ntr
operreg = status.operation.ptr
Writes to enable, NTR and PTR registers:
status.operation.enable = operreg
status.operation.ntr = operreg
status.operation.ptr = operreg
Set operreg to one of the following values:
0 Clears all bits.
status.operation.CALIBRATING Sets CAL bit (B0).
status.operation.CAL Sets CAL bit (B0).
status.operation.MEASURING Sets MEAS bit (B4).
status.operation.MEAS Sets MEAS bit (B4).
status.operation.PROMPTS Sets PRMPTS bit (B11).
status.operation.PRMPTS Sets PRMPTS bit (B11).
status.operation.USER Sets USER bit (B12).
status.operation.INSTRUMENT_SUMMARY Sets INST bit (B13).
status.operation.INST Sets INST bit (B13).
status.operation.PROGRAM_RUNNING Sets PROG bit (B14).
status.operation.PROG Sets PROG bit (B14).
operreg can also be set to the decimal weight of the bit to be set. Examples:
To set bit B0 (CAL), set operreg to 1 (2
0
).
To set bit B4 (MEAS), set operreg to 16 (2
4
).
To set bit B11 (PRMPTS), set operreg to 2048 (2
11
).
To set more than one bit of the register, set operreg to the sum of their decimal
weights. For example, to set bits B0 and B4, set
operreg to 17 (1 + 16).
