12-116 Instrument Control Library Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 12 topics
status.questionable.*
status.questionable.condition
status.questionable.enable
status.questionable.event
status.questionable.ntr
status.questionable.ptr
* = condition, enable, event, ntr or ptr
Attribute Questionable event status register set.
Usage Reads condition, enable, event, NTR and PTR registers:
quesreg = status.questionable.condition
quesreg = status.questionable.enable
quesreg = status.questionable.event
quesreg = status.questionable.ntr
quesreg = status.questionable.ptr
Writes to enable, NTR and PTR registers:
status.questionable.enable = quesreg
status.questionable.ntr = quesreg
status.questionable.ptr = quesreg
Set quesreg to one of the following values:
0 Clears all bits.
status.questionable.CALIBRATING Sets CAL bit (B8).
status.questionable.CAL Sets CAL bit (B8).
status.questionable.OVER_TEMPERATURE Sets OTEMP bit (B12).
status.questionable.OTEMP Sets OTEMP bit (B12).
status.questionable.INSTRUMENT_SUMMARY Sets INST bit (B13).
status.questionable.INST Sets INST bit (B13).
quesreg can also be set to the decimal weight of the bit to be set. Examples:
To set bit B8 (CAL), set quesreg to 256 (2
8
).
To set bit B12 (OTEMP), set quesreg to 4096 (2
12
).
To set bit B13 (INST), set quesreg to 8192 (2
13
).
To set more than one bit of the register, set quesreg to the sum of their decimal
weights. For example, to set bits B8 and B12, set
quesreg to 4352 (256 + 4096).
