20 (37)
Kemppi OY
MXP 37 PIPE
TECHNICAL DATA
FastMig MXP 37 Pipe
Operating voltage 50 V DC
Rated power 250 W
Output 40 °C 60 % ED 520 A
100 % ED 440 A
Wire feed speed 0.5 – 25 m:min
Wire feed mechanism 4-roll, two motors
Diameter of feed rolls 32 mm
Filler wires ø Fe, Ss 0.6 – 2.0 mm
ø Cored wire 0.8 – 2.4 mm
ø Al 0.8 – 2.4 mm
Wire spool max. weight 20 kg
max. ø 300 mm
Gun connection Euro
Operation temperature range -20…+40 °C
Storage temperature range -40…+60 °C
EMC class A
Degree of protection IP23S
Degree of protection 13.1 kg 590 x 240 x 445 mm
Weight 13.1 kg
FastMig MXP 37 Pipe is a wire feeder designed for demanding professional use and intended for 300 mm wire spool. It can be
used with both FastMig X and FastMig Pulse power sources. The special PipeRoot welding process is possible with FastMig X
power source only.
There are two versions of MXP 37 Pipe feeder; Steel and Stainless. Stainless version has pulse-MIG and also some stainless
welding curves with it and Steel version has not those. MXP 37 Pipe wire feeder has own panel XF37.
1. MAIN CIRCUIT DIAGRAM
MXP 37 Pipe wire feeder consists of several circuit cards and separate components.
1.1. Gas valve Y001
• Electromagnetic gas valve operating voltage is +24V. FET V34 is switched on and off with an appropriate frequency
and pulse width resulting +24V operating voltage to gas valve
1.2. Spool space heater (optional)
• Wire feeder’s spool space can be heated if wire feeder is operating in cold or wet conditions. Maximum power for
heating element is 50W (50V, 1A). There is no control circuit for heating element so the heating element is always on
when wire feeder’s supply voltage is connected
