Kemppi FastMig X 450 Service Manual

SERVICE MANUAL
FASTMIG X
25 (37)
Kemppi OY
MXP 38
TECHNICAL DATA
FastMig MXP 38
Operating voltage 50 V DC
Rated power 100 W
Output 40 °C 60 % ED 520 A
100 % ED 440 A
Wire feed speed 0 – 25 m:min
Wire feed mechanism 4-roll, two motors
Diameter of feed rolls 32 mm
Filler wires ø Fe, Ss 0.6 – 1.6 mm
ø Cored wire 0.8 – 1.6 mm
ø Al 0.8 – 1.6 mm
Wire spool max. weight 20 kg
max. ø 300 mm
Gun connection Euro
Operation temperature range -20…+40 °C
Storage temperature range -40…+60 °C
EMC class A
Degree of protection IP23S
Degree of protection 13.1 kg 625 x 243 x 247 mm
Weight 12.5 kg
NOTE !
MXP 38 is technically almost the same feeder than MXF 67. The differencies are:
- different motor control card A001 because wire feeder has voltage sensing connector X16 on card
- wire feeder has own voltage sensing cable connectors (front and back) for measuring cable
- MXP 38 include own panel unit XF38
