4 (37)
Kemppi OY
FASTMIG X 450
TECHNICAL DATA
Fastmig X 450
Connection voltage 3~50:60 Hz 400 V, -15…+20 %
Rated power 60 % ED 22.1 kVA
100 % ED 16.0 kVA
Connection cable HO7RN-F 4G6 (5 m)
Fuse (delayed) 35 A
Output 40 °C 60 % ED 450 A
100 % ED 350 A
Welding current and voltage range MMA 15 A:20 V – 450 A:46 V
U0 = 80 – 98 V
Open circuit power 100 W
Power factor at max. current 0.88
Efficiency at 100 % ED 87 %
Operating temperature range -20…+40 °C
Storage temperature range -40…+60 °C
EMC class A
Minimum short circuit power Ssc of supply network*
5.5 MVA
Degree of protection IP23S
External dimensions L x W x H 590 x 230 x 430 mm
Weight 38 kg
Voltage supply for auxiliary devices 50 V DC : 100 W
Fuse (delayed), aux device 6.3 A
Suitable for generator use 35 kVA
This equipment complies with IEC 61000-3-12 provided that the short-circuit power (Ssc) is greater than or equal to 5.5 MVA at
the interface point between the user’s supply and the public supply network. It is the responsibility of the installer or user of
the equipment to ensure, by consultation with the distribution network operator if necessary, that the equipment is connected
only to a supply with a short-circuit power Ssc greater than or equal to 5.5 MVA.
FastMig X 450 is an inverter power source. Topology of the main power circuit is full bridge. The full bridge topology requires
four power switches which are implemented using IGBT module. Switching frequency of the power switches is 20 kHz. Power
source is controlled by microcontroller with the help of FPGA. This means that welding characteristics are controlled by differ-
ent programs.
Power source and wire feeder consists of several circuit cards and separate components and here are mentioned main parts
functions and operations.
