Kemppi MasterTig 235ACDC User Manual

MasterTig 235ACDC, 325DC, 335ACDC, 425DC
Operating manual - EN
MASTERTIG 235ACDC GM
235ACDC GM
(VRD locked on)
Feature Description Value
External dimensions LxWxH
544 x 205 x 443 mm 544 x 205 x 443 mm
Weight without accessories
19.1 kg 19.1 kg
Arc-on signal for relay
24 V / 50 mA 24 V / 50 mA
Voltage supply for cooling unit U
cu
220...240 V (cooler not sup-
ported in 110 V)
240 V (cooler not supported in
110 V)
Recommended generator power
(min)
S
gen
8 kVA 8 kVA
Wireless communication type:
- Control panels MTP23X, MTP33X,
MTP35X
(1
- Remote controls HR45, FR45
(1
Transmitter frequency
and power
2.4 GHz Bluetooth, 2400-
2483.5 MHz, 10 dBm
2.4 GHz Bluetooth, 2400-
2483.5 MHz, 10 dBm
Wired communication type
Remote
Analog Analog
CAN BUS
Kemppi Remote-Bus Kemppi Remote-Bus
Arc striking voltage
5...11 kV 5...11 kV
Stick electrode diameters ø mm
1.6...5.0 mm 1.6...5.0 mm
TIG welding cable connection type
R1/4 R1/4
Standards
IEC 60974-1,-3,-10
IEC 61000-3-12
GB 15579.1
IEC 60974-1,-3,-10
IEC 61000-3-12
AS 60974.1-2006
GB 15579.1
1)
NO: These devices are not allowed to be used within a 20 km radius of the centre of Ny-Ålesund at Svalbard,
Norway. This restriction applies to any 2-32 GHz transmitter operation.
© Kemppi
63
1920900 / 2052

Kemppi MasterTig 235ACDC Specifications

General

Brand	Kemppi
Model	MasterTig 235ACDC
Category	Welding System
Language	English
