Kemppi MinarcTig Evo 200 Service Manual

Service manual MinarcTig Evo 200
Version 1.1.5.
29.9.2015
13
Kemppi Oy
3.4.5. Setup parameters
To enter the setup you have to press back and forward arrows for three seconds:
Parameter
Explanation
A.
1
TIG slopes to minimum current
0*
TIG current at arc stop is 15 % of welding current
b.
1
no load voltage 30 V (VRD function)
0*
no load voltage 95 V
C.
1
by 2T the downslope is cut off by short (<0,4 s) action of the torch switch
0*
current can be sloped down and up again
d.
3
Minilog + SearcArc
2
4T-LOG + Minilog
1*
Minilog
0
4T-LOG
E.
Current Level at ignition (with upslope)
5-40%
Range
20 % *
Factory default
F.
1
Factory settings recall
0*
Factory default
h.
Pregas time minimum
0.0- 2.0 s
Range
0.0 s*
Factory default
J.
Postgas time minimum
0-10 s
Range
1 s*
Factory default
L.
Pregas time maximum
5-20 s
Range
10 s*
Factory default
o.
Postgas time maximum
15-99 s
Range
30 s*
Factory default
S.
MMA Dynamics adjustment
-3…5
Range
0*
Factory default
 * (asterix) presents the factory default setting
Press 3 seconds for entering setup

Kemppi MinarcTig Evo 200 Specifications

General

Input Voltage	230 V
Protection Class	IP23
Power Factor	0.99
Welding Process	TIG, MMA
Duty Cycle TIG	35% at 200 A
Standards	IEC 60974-1, IEC 60974-10
