3. TECHNICAL INFORMATION
3.1. Technical data
MinarcTig Evo 200
Connection voltage
1~50/60 Hz
230V ± 15%
Rated power
25 % ED TIG
200 A/4.5 kVA
35 % ED MMA
170 A/ 5.8 kVA
Supply current, I
max1
TIG
19.8 A
MMA
25.3 A
Supply current, I
eff1
TIG
12.1 A
MMA
15.0 A
Connection cable
HO7RN-F
3G1.5 (1.5mm
2
, 3m)
Fuse
Type C
16A
Duty cycle 40° C
TIG
35 % ED 200 A/18 V
100 % ED 140 A/15.6 V
MMA
35 % ED 170 A/26.8 V
100 % ED 110 A/24.4 V
Welding range
TIG
5 A/10.2 V - 200 A/18 V
MMA
10A/20.4 V – 170 A/26.8 V
No-load voltage; peak
95 V (VRD 30V)
Idle power
TIG
10 W
MMA
30 W
Power factor at 100 % ED
TIG
0.98
MMA
0.98
Efficiency at 100 % ED
TIG
76 %
MMA
82 %
Arc striking voltage
6-12kV
MMA welding electrodes
MMA
Ø 1.5mm – 4 mm
External dimensions LxWxH
Height with handle
449x210x358 mm
Weight
11 kg (without cable)
Temperature class
F (155º C)
EMC class
A
Degree of protection
IP23S
Operating temperature range
-20…+40º C
Storage temperature range
-40…+60º C
Standards
IEC60974-1
IEC60974-3
IEC60974-10
IEC61000-3-12
