Kemppi X3 User Manual

19
X3 MIG Welder© Kemppi Oy 2018 1814
OPERATING MANUAL
X3 Wire Feeder 300
Operating voltage U
1
24 V
Gun connection Euro
Wire feed mechanism 4-roll
Filler wires Fe 0.6 – 1.6 mm
MC/FC 0.8 – 2.0 mm
Wire feed speed 0 – 25 m/min
Wire spool weight (max) 20 kg
Wire spool diameter (max) 300 mm
Operating temperature range –20...+40 °C
Storage temperature range –40...+60 °C
Degree of protection IP23S
External dimensions LxWxH 590 x 240 x 445 mm
Weight
Standards IEC 60974-5
IEC 60974-10
The equipment complies with the requirements for the CE mark.

Kemppi X3 Specifications

General

Brand	Kemppi
Model	X3
Category	Welding System
Language	English
