X3 MIG Welder© Kemppi Oy 2018 1814
OPERATING MANUAL
8. ORDERING CODES
X3 Power Source 400 X31004000
X3 Power Source 400 (AU) X31004000AU
X3 Power Source 500 X31005000
X3 Wire Feeder 300 X31003000
Welding guns
MMT 42 3.0 m 6254213MMT
MMT 42 4.5 m 6254214MMT
Interconnection cables
Interconnection cable 50-1.8-G 50 mm², 1.8 m, max. 300 A 6260508
Interconnection cable 70-1.8-GH 70 mm², 1.8 m 6260518
Interconnection cable 50-5-GH 50 mm², 5 m, max. 300 A 6260500
Interconnection cable 70-5-GH 70 mm², 5 m 6260501
Interconnection cable 50-10-GH 50 mm², 10 m, max. 300 A 6260513
Interconnection cable 70-10-GH 70 mm², 10 m 6260514
Interconnection cable 50-15-GH 50 mm², 15 m, max. 300 A 6260515
Interconnection cable 70-15-GH 70 mm², 15 m 6260516
Interconnection cable 70-20-GH 70 mm², 20 m 6260523
Interconnection cable 70-30-GH 70 mm², 30 m 6260633
Optional extensions
Extension cable 50-10-G 50 mm², 10 m, max. 300 A 6310510
Extension cable 50-15-G 50 mm², 15 m, max. 300 A 6310515
Extension cable 70-10-G 70 mm², 10 m 6310710
Extension cable 70-15-G 70 mm², 15 m 6310715
Earth return cables
Earth return cable, X3 MIG Welder 50 mm², 5 m, max. 300 A 6184511
Earth return cable, X3 MIG Welder 70 mm², 5 m 6184711
Accessories
X3 Wheel Set X37000001
X3 Four Wheel Set X37000002
X3 Wire Feeder mounting kit X37000003
P20 undercarriage 6185261
Fe 0.8 mm, CO₂
N
mm
1 1.5 2 3 4 6 8 10
:
m/min
2.8 4.0 5.0 8.0 11.5 14.0 16.0 18.0
<
V
14.5 17 18 21 24 26.5 29 31.5
;
A
45 60 80 110 140 160 170 190
Fe 0.8 mm, Ar + 15 – 25% CO₂
N
mm
1 1.5 2 3 4 6 8 10
:
m/min
2.8 4.0 5.0 8.0 11.5 14.0 16.0 18.0
<
V
14.5 16.5 17.5 20 22.5 25.3 28 30
;
A
50 70 90 120 150 160 180 200
Fe 1.0 mm, CO₂
N
mm
1.2 1.5 2 3 4 6 8 10 12
:
m/min
2.2 3.0 4.3 6.0 7.3 9.7 12.0 15.0 18.0
<
V
16.5 18.0 19.5 22.2 24.0 27.3 31.0 35.0 38.0
;
A
60 85 120 150 170 200 230 260 285
Fe 1.0 mm, Ar + 15 – 25% CO₂
N
mm
1.2 1.5 2 3 4 6 8 10 12
:
m/min
2.2 3.0 4.3 6.0 7.3 9.7 12.0 14.5 18.0
<
V
15.6 17.2 18.8 19.8 21.4 25.9 31.5 33.8 35.0
;
A
60 90 125 155 170 205 240 280 300
Fe 1.2 mm, CO₂
N
mm
1 1.5 2 3 4 6 8 10 12 16 20
:
m/min
1 2 3 3 4.5 6 8.5 10 11 12.5 14
<
V
14.2 17 19 19.8 22 24 29.5 32 34 37 39
;
A
40 90 120 140 155 185 230 265 280 300 330
Fe 1.2 mm, Ar + 15 – 25% CO₂
N
mm
1 1.5 2 3 4 6 8 10 12 16 20
:
m/min
1 2 3 3.6 4.5 6 8.5 10 11 12.5 14
<
V
13 15.7 17.5 18.8 20 21.5 27.5 31.5 32.8 35.5 37
;
A
50 95 125 145 165 200 245 285 300 330 345
Fe 1.6 mm, CO₂
N
mm
1.2 1.5 2 3 4 6 8 10 12 16 20
:
m/min
1.0 1.3 1.8 2.8 3.0 3.5 5.0 5.5 6.0 7.0 13.0
<
V
16.0 17.5 19.6 21.5 22.5 24.5 30.0 31.5 33.0 36.0 40.0
;
A
75 95 130 185 195 215 275 295 315 350 500
Fe 1.6 mm, Ar + 15 – 25% CO₂
N
mm
1.2 1.5 2 3 4 6 8 10 12 16 20
:
m/min
1.0 1.3 1.8 2.8 3.5 4.3 5.0 5.8 6.5 7.5 13.0
<
V
13.2 14.6 16.8 20.0 22.0 24.6 27.0 30.4 33.5 36.0 40.0
;
A
85 105 135 195 225 250 280 330 370 400 500
